Not sure whether to use self drilling or self tapping fasteners? Horizon Inc clarifies their key differences, common use cases, and how to pick the right option for your sheet metal and structural projects.
In sheet metal, enclosure, PEB, and equipment assembly, selecting the right screw type directly affects installation speed, joint strength, and product durability. Two of the most widely used fasteners in these applications are self drilling screws and self tapping screws — but they serve different purposes.
At Horizon Inc, we help fabricators, contractors, and OEMs choose the correct screw for every job. In this post, we’ll explain the difference between these fasteners and how to select the right one for your application.
📌 What Are Self Tapping Screws?
These fasteners cut their own threads while being driven into a pre-drilled hole in materials like sheet metal, plastic, or wood. They need an initial pilot hole, but no threading operation beforehand.
Key Features:
- Requires drilled pilot hole
- Cuts matching threads in the substrate
- Comes in various points (sharp, blunt, notched)
Common Uses:
✔ Sheet metal ducts
✔ Electrical enclosures
✔ Light-duty fastening applications
✔ General applications in pre-drilled holes
📌 What Are Self Drilling Screws?
These screws combine a drill bit tip with threading, enabling them to create a hole and form mating threads in one continuous process—no pilot hole needed.
Key Features:
- Drills through metal without pre-drilling
- Cuts threads while drilling
- Allows faster installation
- Often paired with bonded washers for waterproof seals
Common Uses:
✔ PEB structures and roofing
✔ Solar panel mounting systems
✔ Steel framing and fabrication
✔ Outdoor telecom cabinets and shelters
📌 Key Differences: Self Tapping vs Self Drilling Screws
| Feature | Self Tapping Screw | Self Drilling Screw |
|---|---|---|
| Pilot Hole Required | Yes | No |
| Drilling Capability | No (forms threads only) | Yes (drills and threads) |
| Installation Speed | Slower | Faster |
| Typical Application | Light-duty, pre-drilled sheets | Heavy-duty, structural, roofing |
| Waterproofing Option | Rare | Common with bonded washers |
📌 Why It Matters
Using the drill-tip fasteners over traditional tappers saves time and labor costs during high-volume assembly. Conversely, choosing thread-cutting screws is beneficial for delicate sheet applications sensitive to drilling stress. Selecting the right fastener improves joint reliability, reduces production errors, and extends product service life.
📌 Why Choose Horizon Inc for Screws
✔ Extensive range of both types of screws ✔ Variety of head styles: hex, CSK, truss, pan
✔ Steel, stainless steel, and plated variants
✔ Bonded washer options for waterproof connections
✔ Reliable stock and expert application advice
📌 Final Word
Both self drilling and self tapping screws play vital roles in metal and structural assemblies. Choosing the best fastener is key to safe, efficient, and durable joints. Horizon Inc supports you with industry-grade products tailored for your needs.
